HD SMD2121 P2.5mm Full Color Rental LED Screens Module / Led Video Wall

Shenzhen Jinhe Optoelectronics Technology Co.,Ltd
Shenzhen Jinhe Optoelectronics Technology Co.,Ltd
City: Shenzhen
Province/State: Guangdong
Country/Region: China
Tel: 86-755-29366269
Contact Person:
Mr Jude

HD SMD2121 P2.5mm Full Color Rental LED Screens Module / Led Video Wall

Brand Name : Jinhe
Model Number : P2.5
Certification : CE/ROHS/FCC
Place of Origin : China
MOQ : 1 square meter
Price : Negotiable
Payment Terms : T/T, Western Union
Supply Ability : 2,000 square meters per month
Delivery Time : 15 working days after receiving deposit
Packaging Details : Packed in road cases
Usage : Indoor
Display Function : Video
Color : Full Color
Module size : 160 * 160
Brightness : ≥1200
Life span : 100000hours
Drive method : 32
pixel configuration : SMD2121
Contact Now

HD Full Color Display Rental LED Screen LED Module P2.5 Indoor LED Display 160mmx160mm

Technical Paremeter

Small pitch Full color LED Screen

YESH TECH indoor small pitch p2 led screen for manufacturers

ModulePixel Pitch2mm2.5mm
Module Size(W*H)200mm*300mm160mm*160mm
Module Resolution(W*H)100dots*150dots64dots*64dots
Module Weight0.4KG0.4KG
Max Power Consumption50W40W
Pixel ConfugurationSMD1010 3in1 black ledsSMD1010 3in1 black leds
CabinetCabinet Size(W*H*D)400mm*300mm*66mm400mm*300mm*66D
Cabinet Resolution(W*H)200dots*150dots160dots*120dots
Cabinet Area0.12sqm0.12sqm
Cabinet Weight4.6KG4.6KG
Pixel density250,000dots/sqm160,000dots/sqm
Maintenance MethodBack maintenanceBack maintenance
Cabinet MaterialDie casting AluminumDie casting Aluminum
Cabinet Evenness≤0.2mm≤0.2mm
ScreenSingle led Brightness CalibrationYESYES
Single led Chroma CalibrationYESYES
White Balance Brightness≥1000nits≥1200nits
Viewing Angle(H/V)160°/160°160°/160°
Contrast Ratio4000:14000:1
Max Power Consumption120W/cabinet; 1000W/sqm95W/cabinet; 791W/sqm
Working VoltageAC90-264V, 47-63HzAC90-264V, 47-63Hz
Refresh frame frequency50&60Hz50&60Hz
Driving Method1/30 scan1/32 scan
Gray Scale16,38416,384
Refresh Rate≥2000Hz≥2000Hz
Life Span50,000H50,000H
Processing Depth16bit/65536 levels per color16bit/65536 levels per color
Operating environment temperature/humidity-10~+40/10%~80%RH-10~+40/10%~80%RH
Storage temperature/humidity-20~+60/10%~85%RH-20~+60/10%~85%RH


Important Knowledge of Led display
1. What is LED?
LED is sanded for Light Emitting Diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.

2. What are Pixel Pitch, Pixel Density, LED QTY, and Pixel Configuration?
Pixel Pitch is the distance between neighboring pixels.
Pixel Density is the quantity of pixels per square meter.
LED QTY is the quantity of LED lamps per square.
Pixel Configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.

3. What are LED Type, Module size and Module resolution?
LED Type is the description of LED lamp, for instance, the brand, the shape in physical, the size of the lamp, etc.
Module size is the measurement of a module.
Module resolution is the number of pixels per module.

4. What is Drive Method, driving IC and Power supply
Drive Method: always we use static, 1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former. We always use the static outdoor, and use the different kinds of scan indoor.
Driving IC is the generic term for several kinds of IC, that are used to control the LED lamps, and as a bridge between the control system and lamps.
Power supply: a kind of device that used as a transfer from 220V AC into 5V DC. It always seems like a box in the cabinet.

5. What is viewing angle?
Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance. It includes horizontal viewing angle and vertical viewing angle.
